Directional solidification is a casting technique in which a specific temperature gradient is established within the mold shell, causing the molten metal to solidify in a desired crystallographic orientation opposite to the direction of heat flow. Directional solidification is typically applied in investment casting, vacuum casting, and high-temperature alloy manufacturing.
Principle of Directional Solidification
Two conditions must be met to achieve directional solidification:
1.Heat must flow in a single direction, perpendicular to the advancing solid–liquid interface.
2.There must be no stable nucleation in the molten metal ahead of the growing crystal interface.
To meet these conditions, it is essential to suppress lateral heat dissipation and to create a sufficiently large temperature gradient in the molten zone near the solid–liquid interface. These are fundamental to ensuring the termination of non-directional grain growth and the correct orientation of columnar or single-crystal structures.
For successful directional solidification, the solidification interface must maintain stable, directional growth. It is also necessary to suppress the formation of significant compositional undercooling in front of the interface, which can lead to the formation of stray grains.
This requires the following key process measures:
1.Strict unidirectional heat dissipation: The solidification system must always maintain a positive temperature gradient in the direction of columnar grain growth, and lateral heat dissipation must be completely prevented to avoid nucleation and grain growth near the mold walls in front of the interface.
2.Minimization of heterogeneous nucleation in the melt: This involves improving the purity of the molten metal to avoid nucleation ahead of the interface.
3.Avoidance of convection, stirring, or vibration in the molten metal: This prevents stray grain movement ahead of the interface. For alloys where grain density is greater than that of the molten metal, the best way to suppress natural convection is to perform unidirectional solidification from bottom to top.


Directional Solidification Process
According to the theory of constitutional undercooling, achieving a planar solidification structure after directional solidification depends primarily on both alloy characteristics and process parameters. The alloy-related factors include solute concentration, the slope of the liquidus line, and diffusion parameters in the liquid phase. The process parameters include temperature gradient and solidification rate.
When alloy composition is fixed, the control of the solidification structure relies on the selection of process parameters—among which the temperature gradient on the liquid side of the solid–liquid interface is the key. Therefore, increasing the temperature gradient is central to advancing directional solidification technology. A higher temperature gradient not only helps to achieve an ideal alloy microstructure and improved properties, but also allows for a faster solidification rate, thereby enhancing equipment productivity.
There are two main types of directional solidification methods:
1.Ex-furnace crystallization methods
2.In-furnace single-phase solidification methods
